Base Program
* Series echoes, filter-swept, ping-ponged & chopped into bite-sized pieces.
* Further modulated, smeared, pitch-shifted and gently mangled downstream.
* With staccato input, it can function as a normal delay line (well, almost).
* Sustained notes bring out the sequencing chaser effects.
* Insert Mode Program. Program Mix 50%.
* Filter Pong into Stutter.
* Optional Parallel Routing pushes deeper modulations up front.
* All controls programmed for an interactive approach.
HOTKNOBS
Program [P] HotKnob – default (20 OR CC#1)
* Overall adjustment for delay times & stutter buffer length.
* Range of influence – TAP: (30-500) BPM switch.
* Alternate use – REPEAT buffer modulator.
Preset [A] HotKnob – default (5 OR EXP2)
* Increased diffusion and feedback.
* Alternate foot control – secondary expression pedal.
Preset [B] HotKnob – default (20 OR [P] HotKnob)
* Adjust stuttering rate & smearing.
* Alternate control mapping – the Program HotKnob.
PEDALS
EXP1 (saved @ full Heel)
* Increase modulation speed with decreasing depth – Filter Pong.
* Increase modulation rate & detuning with decreasing mod depth – Stutter.
EXP2 (saved @ full Heel)
* Increase diffusion and feedback for Filter Pong.
* Increase amount of spread type, reverb presence, and stereo width for Stutter.
SWITCHES
* AUX 1,2,3 mapped to HS1, HS2, HS3 (momentary action)
* AUX 4,5,6 mapped to HS1, HS2, HS3 (latching action)
Program Alternates
0). Chance Stutter – tiny buffer – intervals up – sine/RND mods.
1). Manual Stutter – small buffer – octave up – triangle mods.
2). Env Stutter – med. buffer – ramping unison smear – square mods.
3). Env Stutter – large buffer – RND intervals braking – sine mods.
PERFORM
1). [P]Act/Byp
2). REPEAT (M)
3). TAP: 120 BPM
4). HS1 (AKA Stutterfoot)
5). REPEAT (L)
6). STUTTER (M)
See the Program Notes for the specifics on external control parameters & MIDI mappings.
I used this effect (HS1) on this track on the lead guitar melody from 1:19 – 1:40
https://open.spotify.com/track/0cBcNxLI2noTNF5FJw9n9Y?si=3becca4d4388440f
