Base Program
* Unstable reverb/delay, sliced into grains, flipped, deformed, panned & filtered.
* Each variation has its own reflections footprint, warp signature & secondary reverb.
* Insert Mode Program. Program Mix 50%. Adjust for prominence of effect.
* Wormhole into GrainMod. Smoothed & washed out in the optional Parallel routing.
* All controls programmed for an interactive approach.
HOTKNOBS
Program [P] HotKnob – default (30 OR CC#1)
* Macro adjustment over the effect: size, shape, diffusion, EQ, warp, grain buffer.
* Alternate use – external modulation over the folds & creases in time & space.
Preset [A] HotKnob – default (5 OR EXP1)
* Adjust the depth & rate of wormhole instability.
* Alternate foot control – primary expression pedal.
Preset [B] HotKnob – default (65 OR CC#2)
* Adjust the grain direction with two bipolar modulation depths.
* Forward delays + negative mods. Reverse delays + positive mods.
PEDALS
* Expression pedal movements can override some HotSwitch settings.
* Retrigger HotSwitch to reset to default values.
EXP1 (saved @ full Heel)
* Increases speed of reverb bends, grain triggers, duration changes & filter sweeps.
* Collapses the stereo grain FX down to a more centralized focus.
* Decrease reverb bending depth and filter influence.
EXP2 (saved @ full Heel)
* Fades in secondary reverb & decay time.
* Blurs, homogenizes & extends the effect structure forming upstream.
SWITCHES
* Aux 0 = default
* AUX 1,2,3 mapped to HS1, HS2, HS3 (momentary action)
* AUX 4,5,6 mapped to HS1, HS2, HS3 (latching action)
Program Alternates
0A). [W/H] brightest medium reverb & delay – medium rapid WARP.
0B). [G/M] Env trig – >REV – mixed mod waveforms – HP filter – min 2nd reverb.
1A). [W/H] balanced large reverb + medium delay – multi-phasic WARP.
1B). [G/M] Manual retrig – +REV – square waveforms – LP filter – short 2nd reverb.
2A). [W/H] bright small reverb + longer delays – lengthy subtle WARP.
2B). [G/M] Env trig – FWD – triangle waveforms – HP filter – long 2nd reverb.
3A). [W/H] longest dark reverb & delays – multiple long WARP formations.
3B). [G/M] Env trig – >FWD – mixed mod waveforms – HP filter – medium 2nd reverb.
PERFORM
1). [P] Act/Byp
2). HS2 [L]
3). HS3 [L]
4). HS1 [L]
5). WARP [L]
6). RETRIGGER [M]
See the Program Notes for specifics on external control parameters & MIDI mappings.
